Key Features:
Ø Adpoting multi-feed point technology that has a more accurate phase value and reduces the impact of the antenna on the survey error.
Ø Supports BDS, GPS, GLONASS, GALILEO, QZSS, SBAS, IRNSS and L-Band multi-system compatibility.
Ø Unique structural design, small size, lightweight and good portability.
Electrical Specifications
Frequency Range: 1164~1300MHz & 1525~1610MHz
Gain: ≥4 dBi (Peak gain)
Polarization: RHCP
Axial Ratio: ≤ 3dB
Azimuth Coverage: 0-360°
Low Elevation Coverage: -90°-90°
Phase Centre Error: ≤±2 mm
LNA Specifications
LNA Gain: 39±2 dB
VSWR: ＜2.0
Noise Figure: ＜2.0 dB
Gain Flatness: ±2 dB
In Band Group Delay Fluctuation: ≤5ns
Voltage: 3.3~16 VDC
Working Current: ≤50mA
Mechanical Specifications
Output Connector: MCX-J
Dimension: Φ81.5×20.5mm
Weight: ≤75g
Operating Temperature: -45℃～+85℃
Storage Temperature: -55℃～+85℃
Diagram
