Key Feature:
Ø With higher precision phase value and smaller survey error.
Ø Wide compatibility, capable of receiving multiple systems and multiple frequency bands.
Ø With metal bottom shell, the structure is solid and reliable, durable and strong.
Ø With metal bottom shell, the structure is solid and reliable, durable and strong.
Ø The disc-shaped design has low wind resistance and is beautiful and reliable.
Ø Meets waterproof grade IP67.
Electrical Specifications
Frequency Range: 1164～1300MHz & 1525～1615MHz
Polarization: RHCP
Antenna Gain: ≥7.0 dBi (Maximum gain)
Axial Ratio: ≤3dB (Elevation angle 90°)
Front-Back Ratio: ≥20 dB (±60°)
Phase Center Error: ≤2mm
LNA Specifications
Gain: 39±2dB
VSWR: ≤1.8
Noise Figure: ≤2.0dB
Gain Flatness: ±1.5dB
Out-of-Band Rejection: ≥45dBc @ F0±200 MHz
In-Band Group Delay Fluctuation: ≤5ns
Voltage: 3.3~15 VDC
Working Current: ≤50mA
Mechanical Specifications
Dimension: Φ152×62mm
Connector: TNC-K
Weight: ≤450g
Operating Temperature: -40℃~+70 ℃
Storage Temperature: -40℃~+70 ℃
Diagram
